SF10A400HD Description
The SF10A400HD is ideally as boost diode in discontinuous
or critical mode power factor corrections.
The device is also intended for use as a freewheeling diode
in power supplies and other power switching applications.
SF10A400HD Features
High voltage and high reliability
Ultrafast reverse recovery time
High speed switching
Low power loss and High efficiency
Halogen-free component and RoHS compliant device
SF10A400HD Applications
General purpose
Switching mode power supply
Free-wheeling diode for motor application
Power switching circuits
DC-DC converter systems
Absolute Maximum Ratings(Limiting Values)
Thermal Characteristics
Electrical Characteristics
Note :(1) Pulse test :tP ≤380 ㎲,Duty cycle≤2%
