74F534SJ high speed low-power octal

General Description

The 74F534 is a high speed, low-power octal
D-type flip-flop featuring separate D-type
inputs for each flip-flop and 3-STATE outputs
for bus-oriented applications. A buffered
Clock (CP) and Output Enable (OE) are common
to all flip-flops. The 74F534 is the same as
the 74F374 except that the outputs are inverted.

Features

Edge-triggered D-type inputs
Buffered positive edge-triggered clock
3-STATE outputs for bus-oriented applications

Logic Symbols

Connection Diagram

Logic Diagram

Please note that this diagram is provided only for the understanding
of logic operations and should not be used to estimate propagation delays.
