Description
The LIS3MDL is an ultra-low-power highperformance
three-axis magnetic sensor.
The LIS3MDL has user-selectable full scales of
±4/±8/±12/±16 gauss.
The self-test capability allows the user to check
the functioning of the sensor in the final
application.
The device may be configured to generate
interrupt signals for magnetic field detection.
The LIS3MDL includes an I 2 C serial bus interface
that supports standard and fast mode (100 kHz
and 400 kHz) and SPI serial standard interface.
The LIS3MDL is available in a small thin plastic
land grid array package (LGA) and is guaranteed
to operate over an extended temperature range of
-40 °C to +85 °C.
Features
Wide supply voltage, 1.9 V to 3.6 V
Independent IO supply (1.8 V)
±4/±8/±12/±16 gauss selectable magnetic full
scales
Continuous and single-conversion modes
16-bit data output
Interrupt generator
Self-test
I 2 C/SPI digital output interface
Power-down mode / low-power mode
ECOPACK®, RoHS and “Green” compliant
Applications
Magnetometers
Compasses
Block diagram
Pin connections
I 2 C slave timing diagram
LIS3MDL electrical connections
