Description
The LIS332AR is a miniaturized low-power 3-axis
linear accelerometer belonging to the “nano”
family of ST motion sensors. It includes a sensing
element and an IC interface to provide an analog
signal to the external world.
The sensing element, capable of detecting the
acceleration, is manufactured using a dedicated
process developed by ST to produce motion
sensors and actuators in silicon.
The IC interface is manufactured using a CMOS
process that allows the design of a dedicated
circuit which is trimmed to better match the
sensing element characteristics.
The LIS332AR has a full-scale of ±2 g,and is
capable of measuring accelerations over a
maximum bandwidth of 2.0 kHz. The device
bandwidth may be reduced by using external
capacitors. The self-test capability allows the user
to check the functioning of the sensor in the final
application.
ST is already in the field with several hundred
million sensors which have received excellent
acceptance from the market in terms of quality,
reliability and performance.
The LIS332AR is provided in a plastic land grid
array (LGA) package.
Several years ago ST successfully pioneered the
use of this package for accelerometers. Today, ST
has the widest manufacturing capability and
strongest expertise in the world for production of
sensors in plastic LGA packages.
Features
Single voltage supply operation
±2 g full-scale
High stability over temperature
Ratiometric output voltage
Power-down mode
Embedded self-test
10000 g high shock survivability
ECOPACK ® RoHS and “Green” compliant
(see Section 7)
Applications
Tilting applications
Free-fall detection
Gaming
Anti-theft systems
Inertial navigation and motion tracking
Block diagram
Pin connection
LIS332AR electrical connection
P/N Temp(0℃） Package Packing
LIS332AR -40 to +85 LGA-16 490pcs/Tray
LIS332ARTR -40 to +85 LGA-16 1/Reel
