STM8AF系列型号热卖/封装图片

型號	品牌	批號	數量	封裝	備注
STM8AFXXX	ST	22+	5000000	LQFP	Original 全新原裝

STM8AFXXX pdf規格書

型號	狀態	品脾	批號	封裝	數量	備注
STM8AF5168	NRND	ST	22+	LQFP	50000	Original 全新原裝
STM8AF5179	NRND	ST	22+	LQFP	50000	Original 全新原裝
STM8AF5188	NRND	ST	22+	LQFP	50000	Original 全新原裝
STM8AF5189	NRND	ST	22+	LQFP	50000	Original 全新原裝
STM8AF518A	NRND	ST	22+	LQFP	50000	Original 全新原裝
STM8AF5198	NRND	ST	22+	LQFP	50000	Original 全新原裝
STM8AF51A8	NRND	ST	22+	LQFP	50000	Original 全新原裝
STM8AF51A9	NRND	ST	22+	LQFP	50000	Original 全新原裝
STM8AF51AA	NRND	ST	22+	LQFP	50000	Original 全新原裝
STM8AF5268	Active	ST	22+	LQFP	50000	Original 全新原裝
STM8AF5269	Active	ST	22+	LQFP	50000	Original 全新原裝
STM8AF5288	Active	ST	22+	LQFP	50000	Original 全新原裝
STM8AF5289	Active	ST	22+	LQFP	50000	Original 全新原裝
STM8AF528A	Active	ST	22+	LQFP	50000	Original 全新原裝
STM8AF52A8	Active	ST	22+	LQFP	50000	Original 全新原裝
STM8AF52A9	Active	ST	22+	LQFP	50000	Original 全新原裝
STM8AF52AA	Active	ST	22+	LQFP	50000	Original 全新原裝
STM8AF6146	NRND	ST	22+	LQFP	50000	Original 全新原裝
STM8AF6166	NRND	ST	22+	LQFP	50000	Original 全新原裝
STM8AF6178	NRND	ST	22+	LQFP	50000	Original 全新原裝
STM8AF6189	NRND	ST	22+	LQFP	50000	Original 全新原裝
STM8AF6226	Active	ST	22+	LQFP	50000	Original 全新原裝
STM8AF6246	Active	ST	22+	LQFP	50000	Original 全新原裝
STM8AF6248	Active	ST	22+	LQFP	50000	Original 全新原裝
STM8AF6266	Active	ST	22+	LQFP	50000	Original 全新原裝
STM8AF6268	Active	ST	22+	LQFP	50000	Original 全新原裝
STM8AF6269	Active	ST	22+	LQFP	50000	Original 全新原裝
STM8AF6286	Active	ST	22+	LQFP	50000	Original 全新原裝
STM8AF6288	Active	ST	22+	LQFP	50000	Original 全新原裝
STM8AF6289	Active	ST	22+	LQFP	50000	Original 全新原裝
STM8AF628A	Active	ST	22+	LQFP	50000	Original 全新原裝
STM8AF62A8	Active	ST	22+	LQFP	50000	Original 全新原裝
STM8AF62A9	Active	ST	22+	LQFP	50000	Original 全新原裝
STM8AF62AA	Active	ST	22+	LQFP	50000	Original 全新原裝

STM8AF系列圖片

STM8AFXXXAutomotive 8-bit MCU, with up to 128 Kbytes Flash, data EEPROM,
10-bit ADC, timers, LIN, CAN, USART, SPI, I2C, 3 to 5.5 V

STM8AFXXXIntroduction
This datasheet refers to the STM8AF52xx, STM8AF62xx, STM8AF51xx, and STM8AF61xx
products with 32 to 128 Kbytes of program memory.
In the order code, the letter ‘F’ refers to product versions with Flash and data EEPROM, ‘H’
to product versions with Flash only, and ‘P’ to product versions with FASTROM. The
identifiers ‘F’, ‘H’, and ‘P’ do not coexist in a given order code.
The datasheet contains the description of family features, pinout, electrical characteristics,
mechanical data and ordering information.
● For complete information on the STM8A microcontroller memory, registers and
peripherals, please refer to STM8S and STM8A microcontroller families reference
manual (RM0016).
● For information on programming, erasing and protection of the internal Flash memory
please refer to the STM8S and STM8A Flash programming manual (PM0051).
● For information on the debug and SWIM (single wire interface module) refer to the
STM8 SWIM communication protocol and debug module user manual (UM0470).
● For information on the STM8 core, please refer to the STM8 CPU programming manual
(PM0044).

STM8AFXXXDescription
The STM8AF52xx, STM8AF62xx, STM8AF51xx, and STM8AF61xx automotive 8-bit
microcontrollers described in this datasheet offer from 32 Kbytes to 128 Kbytes of non
volatile memory and integrated true data EEPROM. They are referred to as high density
STM8A devices in the STM8S and STM8A microcontroller families reference manual
(RM0016).
The STM8AF51xx and STM8AF52xx series feature a CAN interface.
All devices of the STM8A product line provide the following benefits: reduced system cost,
performance and robustness, short development cycles, and product longevity.
The system cost is reduced thanks to an integrated true data EEPROM for up to 300 k
write/erase cycles and a high system integration level with internal clock oscillators,
watchdog, and brown-out reset.
Device performance is ensured by 20 MIPS at 24 MHz CPU clock frequency and enhanced
characteristics which include robust I/O, independent watchdogs (with a separate clock
source), and a clock security system.
Short development cycles are guaranteed due to application scalability across a common
family product architecture with compatible pinout, memory map and and modular
peripherals. Full documentation is offered with a wide choice of development tools.
Product longevity is ensured in the STM8A family thanks to their advanced core which is
made in a state-of-the art technology for automotive applications with 3.3 V to 5.5 V
operating supply.
All STM8A and ST7 microcontrollers are supported by the same tools including
STVD/STVP development environment, the STice emulator and a low-cost。

STM8AFXXXFeatures
■ Core
– Max fCPU: 24 MHz
– Advanced STM8A core with Harvard
architecture and 3-stage pipeline
– Average 1.6 cycles/instruction resulting in
10 MIPS at 16 MHz fCPU for industry
standard benchmark
■ Memories
– Program memory: 32 to 128 Kbytes Flash
program; data retention 20 years at 55 °C
– Data memory: up to 2 Kbytes true data
EEPROM; endurance 300 kcycles
– RAM: 2 Kbytes to 6 Kbytes
■ Clock management
– Low-power crystal resonator oscillator with
external clock input
– Internal, user-trimmable 16 MHz RC and
low-power 128 kHz RC oscillators
– Clock security system with clock monitor
■ Reset and supply management
– Wait/auto-wakeup/Halt low-power modes
with user definable clock gating
■ Interrupt management
– Nested interrupt controller with 32 vectors
– Up to 37 external interrupts on 5 vectors
■ Timers
– 2 general purpose 16-bit timers with up to 3
CAPCOM channels each (IC, OC, PWM)
– 8-bit AR basic timer with 8-bit prescaler
– Auto-wakeup timer
– Window and independent watchdog timers
■ I/Os
– Up to 68 user pins (11 high sink I/Os)
– Highly robust I/O design, immune against
current injection
■ Communication interfaces
– High speed 1 Mbit/s CAN 2.0B interface
– USART with clock output for synchronous
operation - LIN master mode
– LINUART LIN 2.1 compliant, master/slave
modes with automatic resynchronization
– SPI interface up to 10 Mbit/s or fMASTER/2
– I2C interface up to 400 Kbit/s
■ Analog to digital converter (ADC)
– 10-bit resolution, 2 LSB TUE, 1 LSB
linearity and up to 16 multiplexed channels
■ Operating temperature up to 150 °C

STM8AFXXX汽車的8位單片機,128 kb的Flash,eepm數據,10位ADC,計時器,SPI,I2C,3 - 5.5 V

STM8AFXXX產品介紹
STM8AF62xx,這個數據表是指STM8AF52xx STM8AF51xx,STM8AF61xx產品32到128 kb的程序內存。

指令碼,字母“F”指的是產品版本Flash和數據eepm,“H”產品版本Flash,和“P”與FASTROM產品版本。標識符“F”,“H”,和“P”不共存的一個給定的指令碼。

數據表包含家庭功能的描述,引出線、電氣特性、機械數據。

●STM8A完整信息的單片機內存、寄存器和外圍設備,請參閱STM8S STM8A單片機家庭參考手冊(RM0016)。
●關于編程的信息,消除和保護內部閃存請參閱STM8S和STM8A Flash編程手冊(PM0051)。
●調試信息和游泳(單線接口模塊)指STM8游泳通信協議和調試模塊用戶手冊(UM0470)。
●關于STM8核心的信息,請參閱STM8 CPU編程手冊(PM0044)。

STM8AFXXX產品描述
STM8AF62xx,STM8AF52xx STM8AF51xx,STM8AF61xx本數據表中描述汽車8位微控制器提供從32 kb到128 kb的非易失存儲器和集成eepm真實數據。他們被稱為高密度STM8A設備STM8S和STM8A單片機家庭參考手冊(RM0016)。

STM8AF51xx和STM8AF52xx系列功能接口。

STM8A產品線的所有設備提供以下好處:降低系統成本,性能和魯棒性,較短的開發周期和產品壽命。

系統成本降低由于一個集成的真正的數據eepm 300 k寫/擦除周期和較高的系統集成水平與內部時鐘振蕩器,監管機構和暗光重置。

設備性能保證由24 MHz 20 MIPS CPU時鐘頻率和增強特性包括健壯的I / O,獨立監管機構(一個單獨的時鐘源),和一個時鐘的保障體系。

短開發周期保證由于應用程序的可伸縮性在一個共同的家庭產品架構兼容的引出線,內存映射和模塊化的外圍設備。

產品壽命保證STM8A家族由于他們先進的核心是一個先進的技術為汽車應用與3.3 V至5.5 V操作供應

所有STM8A和ST7微控制器支持同樣的工具包括STVD / STVP開發環境,焦油模擬器和低成本。

STM8AFXXX特性
■核心
- Max fCPU:24 MHz
-先進STM8A核心與哈佛架構和號管道
—平均1.6周期/ 10 MIPS指令導致16兆赫fCPU工業標準的基準
■記憶
-程序內存:32到128 kb的Flash程序;數據保留20年55°C
——數據內存:2 kb的真實數據eepm;300 kcycles耐力
內存:2 kb 6 kb
■時鐘管理
——低功率晶體諧振器與外部時鐘振蕩器輸入
——內部user-trimmable 16兆赫RC和低功耗128 kHz RC振蕩器
—時鐘和時鐘監控安全系統
■重置和供應管理
-等待/ auto-wakeup /停止低功耗模式,用戶可定義時鐘門控
■中斷管理
—嵌套中斷控制器32向量
37 5日外部中斷向量
■計時器
與3 - 2通用16位定時器CAPCOM渠道每個(IC、OC、PWM)
- 8位8位預定標器的基于“增大化現實”技術的基本定時器
—Auto-wakeup計時器
—窗口和獨立的看門狗定時器
■多邊I / Os
- 68用戶密碼(11高水槽I / Os)
—高度健壯的I / O設計,免疫對電流注入
■通信接口
—高速1 Mbit / s可以2.0 b接口
-與時鐘輸出同步操作,林主模式
—林LINUART 2.1兼容,主/從模式自動再同步
- SPI接口10 Mbit / s或fMASTER / 2
I2C接口- 400 Kbit / s
■模擬到數字轉換器(ADC)
2 - 10位分辨率,LSB星期二,1 LSB線性和16多路復用通道
■操作溫度高達150°C

原裝進口，現貨庫存，歡迎來電咨詢：聯系方式如下

名稱：深圳奧尼拓電子有限公司

地址：深圳市福田區中航路都會軒3707-3708室

電話： 19539046113

QQ : 2885745253

企業郵箱：2885745253@qq.com

聯系人：廖麗玲

來源：深圳市奧尼拓電子有限公司

網址：http://www.aunytorchips.com/

STM8AF系列型號熱賣/封裝圖片
