STM8AF6166

型號	品牌	批號	數量	封裝	備注
STM8AF6166	ST	22+	5000000	LQFP	Original 全新原裝

STM8AF6166

pdf規格書

STM8AF6166圖片

Automotive 8-bit MCU, with up to 32 Kbytes Flash, data EEPROM,
10-bit ADC, timers, LIN, SPI, I2C, 3 to 5.5 V

STM8AF6166Features
■ Core
– Max fCPU: 16 MHz
– Advanced STM8A core with Harvard
architecture and 3-stage pipeline
– Average 1.6 cycles/instruction resulting in
10 MIPS at 16 MHz fC
■ Memories
– Flash Program memory: 16 to 32 Kbytes
Flash; data retention 20 years at 55 °C
after 1 kcycle
– Data memory: 0.5 to 1 Kbyte true data
EEPROM; endurance 300 kcycles
– RAM: 1 to 2 Kbytes
■ Clock management
– Low-power crystal resonator oscillator with
external clock input
– Internal, user-trimmable 16 MHz RC and
low-power 128 kHz RC oscillators
– Clock security system with clock monitor
■ Reset and supply management
– Wait/auto-wakeup/Halt low-power modes
with user definable clock gating
– Low consump
■ Interrupt management
– Nested interrupt controller with 32 vectors
– Up to 34 external interrupts on 5 vectors
■ Timers
– Up to 2 general purpose 16-bit PWM timers
with up to 3 CAPCOM channels each (IC,
OC or PWM)
– 8-bit AR basic timer with 8-bit prescaler
– Auto-wakeup timer
– Window and independent watchdog timers
■ Communication interfaces
– LINUART
– LIN 2.1 compliant, master/slave modes
with automatic resynchronization
– SPI interface up to 10 Mbit/s or fMASTER/2
– I2C interface up to 400 Kbit/s
■ Analog-to-digital converter (ADC)
– 10-bit accuracy, 2LSB TUE accuracy, 2LSB
TUE linearity ADC and up to 10 multiplexed
channels with individual data buffer
– Analog watchdog, scan and continuous
sampling mode
■ I/Os
– Up to 38 user pins including 10 HS I/Os
– Highly robust I/O design, immune against
current injection
■ Operating temperature up to 150 °C

STM8AF6166Description
The STM8AF61xx and STM8AF62xx automotive 8-bit microcontrollers offer from 16 to 32
Kbytes of Flash program memory and integrated true data EEPROM. They are referred to
as medium density STM8A devices in the STM8S and STM8A microcontroller families
reference manual (RM0016).
All devices of the STM8A product line provide the following benefits: reduced system cost,
performance and robustness, short development cycles, and product longevity.
The system cost is reduced thanks to an integrated true data EEPROM for up to 300 k
write/erase cycles and a high system integration level with internal clock oscillators,
watchdog, and brown-out reset.
Device performance is ensured by a clock frequency of up to 16 MHz CPU and enhanced
characteristics which include robust I/O, independent watchdogs (with a separate clock
source), and a clock security system.
Short development cycles are guaranteed due to application scalability across a common
family product architecture with compatible pinout, memory map and and modular
peripherals. Full documentation is offered with a wide choice of development tools.
Product longevity is ensured in the STM8A family thanks to their advanced core which is
made in a state-of-the art technology for automotive applications with 3.3 V to 5 V operating
supply.

汽車8位單片機,高達32 kb的Flash,eepm數據,10位ADC,計時器、林、SPI、I2C、3 - 5.5 V

STM8AF6166特性
■核心
– Max fCPU:16兆赫
– 先進STM8A核心與哈佛架構和號管道
– 平均1.6周期/ 10 MIPS指令導致16兆赫fCPU工業標準的基準
■記憶
– Flash程序內存:16至32 kb的Flash;數據保留1 kcycle后20年55°C
– 數據存儲器:0.5 1 kb的真實數據eepm;300 kcycles耐力
– RAM:1到2 kb
■時鐘管理
– 低功率晶體諧振器與外部時鐘振蕩器輸入
– 內部user-trimmable 16兆赫RC和低功耗128 kHz RC振蕩器
– 時鐘和時鐘監控安全系統
■重置和供應管理
– 等待/ auto-wakeup /停止低功耗模式,用戶可定義時鐘門控
■中斷管理
– 嵌套中斷控制器32向量
– 34 5日外部中斷向量
■計時器
– 2通用16位PWM定時器3 CAPCOM渠道每個(IC,OC或PWM)
– 先進控制計時器
– 8位8位預定標器的基于“增大化現實”技術的基本定時器
– Auto-wakeup計時器
– 窗口和獨立的看門狗定時器
■通信接口
– LINUART
– 2.1兼容,主/從模式自動再同步
– SPI接口10 Mbit / s或fMASTER / 2
– I2C接口- 400 Kbit / s
■模擬-數字轉換器(ADC)
– 10位的準確性,2 lsb星期二準確性,lsb星期二線性ADC和10多路復用通道與個人數據緩沖區
– 模擬看門狗、掃描和連續采樣模式
■多邊I / Os
– 38用戶針包括10 HS I / o
– 高度健壯的I / O設計,免疫對電流注入
■操作溫度高達150°C

STM8AF6166產品描述
STM8AF61xx和STM8AF62xx汽車8位微控制器提供從16到32 k字節的Flash程序內存和集成eepm真實數據。他們被稱為中密度STM8A設備STM8S和STM8A單片機。

STM8A產品線的所有設備提供以下好處:降低系統成本,性能和魯棒性,較短的開發周期和產品壽命。

系統成本降低由于一個集成的真正的數據eepm 300 k寫/擦除周期和較高的系統集成水平與內部時鐘振蕩器,監管機構和暗光重置。

設備性能保證16兆赫處理器的時鐘頻率和增強特性包括健壯的I / O,獨立監管機構(一個單獨的時鐘源),和一個時鐘的保障體系。

短開發周期保證由于應用程序的可伸縮性在一個共同的家庭產品架構兼容的引出線,內存映射和模塊化的外圍設備。

產品壽命保證STM8A家族由于他們先進的核心是一個先進的技術為汽車應用與3.3 V 5 V操作。
