| 型號 | 品牌 | 批號 | 數量 | 封裝 | 備注 |
| STM8S005K6T6 | ST | 22+ | 5000000 | LQFP | Original 全新原裝 |
STM8S005K6T6
pdf規格書
16 MHz STM8S 8-bit MCU, 32 Kbytes Flash, data
EEPROM,10-bit ADC, timers, UART, SPI, I²C
STM8S005K6T6Features
Core
• 16 MHz advanced STM8 core with Harvard
architecture and 3-stage pipeline
• Extended instruction set
Memories
• Medium-density Flash/EEPROM:
- Program memory: 32 Kbytes of Flash
memory; data retention 20 years at 55°C
after 100 cycles
- Data memory: 128 bytes of true data
EEPROM;enduranceupto100k write/erase
cycles
• RAM: 2 Kbytes
Clock, reset and supply management
• 2.95 V to 5.5 V operating voltage
• Flexible clock control, 4 master clock sources:
- Low power crystal resonator oscillator
- External clock input
- Internal, user-trimmable 16 MHz RC
- Internal low power 128 kHz RC
• Clock security system with clock monitor
• Power management:
- Low power modes (wait, active-halt, halt)
- Switch-off peripheral clocks individually
• Permanentlyactive, low consumptionpower-on
and power-down reset
Interrupt management
• Nested interrupt controller with 32 interrupts
• Up to 37 external interrupts on 6 vectors
Timers
• 2x 16-bit general purpose timers, with 2+3
CAPCOM channels (IC, OC or PWM)
• Advanced control timer: 16-bit, 4 CAPCOM
channels, 3 complementary outputs, dead-time
insertion and flexible synchronization
• 8-bit basic timer with 8-bit prescaler
• Auto wake-up timer
• Window and independent watchdog timers
Communications interfaces
• UART with clock output for synchronous
operation, Smartcard, IrDA, LIN
• SPI interface up to 8 Mbit/s
• I
2C interface up to 400 Kbit/s
Analog-to-digital converter (ADC)
• 10-bit, ±1 LSB ADC with up to 10 multiplexed
channels, scan mode and analog watchdog
I/Os
• Up to 38 I/Os on a 48-pin package including 16
high sink outputs
• Highly robust I/O design, immuneagainst current
injection
Development support
• Embeddedsingle wireinterface module(SWIM)
for fast on-chip programming and non intrusive
debugging
STM8S005K6T6Description
The STM8S005xx value line 8-bit microcontrollers offer 32 Kbytes of Flash program memory,
plus 128 bytes of data EEPROM. They are referred to as medium-density devices in the
STM8S microcontroller family reference manual (RM0016). All devices of the STM8S005xx
value line provide the following benefits: performance, robustness, reduced system cost, and
short develoment cycles.
Device performance and robustness are ensured by true data EEPROM supporting up to 100
000 write/erase cycles, advanced core and peripherals made in a state-of-the art technology,
a 16 MHz clock frequency, robust I/Os, independent watchdogs with separate clock source,
and a clock security system.
The system cost is reduced thanks to high system integration level with internal clock
oscillators, watchdog and brown-out reset.
Common family product architecture with compatible pinout, memory map and modular
peripherals allow application scalability and reduced development cycles.
All products operate from a 2.95 to 5.5 V supply voltage.
Full documentation is offered as well as a wide choice of development tools
16兆赫STM8S 8位單片機,32 kb的Flash,eepm數據,10位ADC,計時器
STM8S005K6T6核心
•16兆赫先進STM8核心與哈佛架構和號管道
•擴展指令集
STM8S005K6T6記憶
•制造Flash / eepm:
——程序內存:32 kb的閃存;數據保留20年100次后55°C
——數據內存:128字節的真實數據eepm;enduranceupto100k
•內存:2 kb
STM8S005K6T6時鐘、復位和供應管理
•操作電壓2.95 V至5.5 V
•靈活的時鐘控制,主時鐘來源:
——低功率晶體諧振器振蕩器
——外部時鐘輸入
——內部user-trimmable 16兆赫RC
——內部低功率128 kHz RC
•時鐘和時鐘監控安全系統
•電源管理:
——低功耗模式(等active-halt,停止)
——單獨關閘外圍時鐘
•Permanentlyactive、低consumptionpower-on和斷電復位
STM8S005K6T6中斷管理
•與32個中斷嵌套中斷控制器
•外部中斷
STM8S005K6T6計時器
•2 x 16位通用定時器,2 + 3 CAPCOM渠道(IC,OC或PWM)
•高級控制定時器:16位、4 CAPCOM渠道,3互補輸出,空時插入和靈活的同步
•8位和8位預定標器基本定時器
•自動喚醒定時器
•窗口和獨立的看門狗定時器
STM8S005K6T6通信接口
•UART與時鐘輸出同步操作,智能卡,紅外線
•SPI接口8 Mbit / s
•2 c接口400 Kbit / s
STM8S005K6T6模擬-數字轉換器(ADC)
•10位,±1 LSB和10多路復用通道ADC,掃描模式和模擬看門狗
STM8S005K6T6I / o
•達38我/ Os 48-pin包包括16個高輸出
•高度健壯的I / O設計,immuneagainst電流注入
STM8S005K6T6開發支持
•Embeddedsingle wireinterface模塊(游泳)快速芯片上的編程和非侵入性的調試
STM8S005K6T6產品描述
STM8S005xx值線8位微控制器提供32 kb的Flash程序內存,再加上eepm 128字節的數據。他們被稱為制造設備STM8S單片機家族參考手冊(RM0016)。STM8S005xx值線的所有設備提供以下好處:性能、魯棒性,降低了系統成本,開發周期短。
設備性能和魯棒性是由真正的數據保證eepm支持多達100 000寫/擦除周期,先進的核心和外圍設備制造的一種先進的技術,一個16 MHz時鐘頻率,健壯的I / o,獨立的監管機構,獨立的時鐘源,和一個時鐘的保障體系。
系統成本降低由于高系統集成水平與內部時鐘振蕩器,監管機構和暗光重置。
常見的家庭產品架構兼容的引出線,內存映射和模塊化的外圍
設備允許應用程序的可伸縮性和縮短開發周期。
所有產品從2.95到5.5 V電源電壓操作。
提供完整的文檔以及多種選擇的開發工具。
