| 型號 | 品牌 | 批號 | 數量 | 封裝 | 備注 |
| STM8S903K3T6C | ST | 22+ | 5000000 | LQFP | Original 全新原裝 |
STM8S903K3T6C
pdf規格書
STM8S903K3T6C Features
Core
• 16 MHz advanced STM8 core with Harvard
architecture and 3-stage pipeline
• Extended instruction set
Memories
• Program memory: 8 Kbytes Flash; data retention
20 years at 55 °C after 10 kcycles
• Data memory: 640 bytes true data EEPROM;
endurance 300 kcycles
• RAM: 1 Kbytes
Clock, reset and supply management
• 2.95 to 5.5 V operating voltage
• Flexible clock control, 4 master clock sources:
- Low power crystal resonator oscillator
- External clock input
- Internal, user-trimmable 16 MHz RC
- Internal low power 128 kHz RC
• Clock security system with clock monitor
• Power management:
- Low power modes (wait, active-halt, halt)
- Switch-off peripheral clocks individually
• Permanently active, low consumption power-on
and power-down reset
Interrupt management
• Nested interrupt controller with 32 interrupts
• Up to 28 external interrupts on 7 vectors
Timers
• Advanced control timer: 16-bit, 4 CAPCOM
channels, 3 complementary outputs, dead-time
insertion and flexible synchronization
• 16-bit general purpose timer, with 3 CAPCOM
channels (IC, OC or PWM)
• 8-bit basic timer with 8-bit prescaler
• Auto wakeup timer
• Window and independent watchdog timers
Communications interfaces
• UART with clock output for synchronous
operation, Smartcard, IrDA, LIN master mode
• SPI interface up to 8 Mbit/s
• I
2C interface up to 400 Kbit/s
Analog to digital converter (ADC)
• 10-bit, ±1 LSB ADC with up to 7 muxed channels
+ 1 internal channel, scan mode and analog
watchdog
• Internal reference voltage measurement
I/Os
• Up to 28 I/Os on a 32-pin package including 21
high sink outputs
• Highly robust I/O design, immune against current
injection
Development support
• Embedded single wire interface module (SWIM)
for fast on-chip programming and non intrusive
debugging
Unique ID: 96-bit key including lot number
STM8S903K3T6CDescription
The STM8S903K3 and STM8S903F3 8-bit microcontrollers offer 8 Kbytes Flash program
memory, plus integrated true data EEPROM. The STM8S microcontroller family reference
manual (RM0016) refers to devices in this family as low-density. They provide the following
benefits: performance, robustness, and reduced system cost.
Device performance and robustness are ensured by advanced core and peripherals made
in a state-of-the art technology, a 16 MHz clock frequency, robust I/Os, independent watchdogs
with separate clock source, and a clock security system.
The system cost is reduced thanks to an integrated true data EEPROM for up to 300
kwrite/erase cycles and a high system integration level with internal clock oscillators, watchdog
and brown-out reset.
Full documentation is offered as well as a wide choice of development tools.
STM8S903K3T6CUnique ID
The devices feature a 96-bit unique device identifier which provides a reference number that
is unique for any device and in any context. The 96 bits of the identifier can never be altered
by the user.
The unique device identifier can be read in single bytes and may then be concatenated using
a custom algorithm.
The unique device identifier is ideally suited:
• For use as serial numbers
• For use as security keys to increase the code security in the program memory while using
and combining this unique ID with software cryptograhic primitives and protocols before
programming the internal memory.
• To activate secure boot processes
16兆赫STM8S 8位單片機,8 kb的Flash,1 kb RAM,640字節eepm,10位ADC,2定時器,UART,SPI,我²C
STM8S903K3T6C產品描述
STM8S903K3和STM8S903F3 8位微控制器提供8 kb的Flash程序內存,加上綜合eepm真實數據。STM8S單片機家族參考手冊(RM0016)是指設備在這個家庭為低密度。他們提供了以下好處:性能、魯棒性,降低了系統成本。
確保設備性能和魯棒性是通過先進的核心和外圍設備的先進的技術,一個16 MHz時鐘頻率,健壯的I / o,獨立的監管機構,獨立的時鐘源,和一個時鐘的保障體系。
系統成本降低由于一個集成的真實數據eepm 300 kwrite /消除周期和較高的系統集成水平與內部時鐘振蕩器,監管機構和暗光重置。
提供完整的文檔以及多種選擇的開發工具。
STM8S903K3T6C特性
核心
•16兆赫STM8核心與哈佛架構和號管道
•擴展指令集
記憶
•程序內存:8 kb的Flash;數據保留20年55°C 10 kcycles
•后數據內存:640字節真實數據eepm;耐力300 kcycles
•內存:1 kb
時鐘、復位和供應管理
•2.95到5.5 V工作電壓
•靈活的時鐘控制,4主時鐘來源:
——低功率晶體諧振器振蕩器
——外部時鐘輸入
——內部user-trimmable 16兆赫RC
-內部低功率128 kHz RC
•時鐘時鐘監控安全系統
•電源管理:
低功耗模式(等active-halt,停止)
——單獨關閘外圍時鐘
•永久活躍,低消費上電和斷電復位
中斷管理
•與32個中斷嵌套中斷控制器
•7日至28日外部中斷向量
計時器
•先進控制計時器:16位、3互補輸出,空時插入和靈活的同步
•16位通用計時器,與3 CAPCOM渠道(IC,OC或PWM)
•8位和8位預定標器基本定時器
•汽車和獨立的看門狗定時器喚醒定時器
•窗口
•通信接口UART與時鐘輸出同步操作,智能卡,紅外線,林主模式
•SPI接口8 Mbit / s
•2 c接口400 Kbit / s
模擬到數字轉換器(ADC)
•10位,±1 LSB ADC高達7 mux渠道+ 1內部通道,掃描模式和模擬看門狗
•內部參考電壓測量
I / o
•28我/ Os 32-pin包包括21個高輸出
•高度健壯的I / O設計,對當前免疫注射
開發支持
•嵌入式單線接口模塊(游泳)快芯片上的編程和非侵入性的調試
惟一的ID:96位的密鑰包括批號
一個96位的唯一的設備標識符的設備功能,提供了一個參考號碼,是獨一無二的任何設備,在任何情況下。的96位用戶標識符不能被改變。
唯一的設備標識符可以在單一字節和閱讀可能會使用一個自定義的連接算法。
獨特的設備標識符是適合:
•用作序列號
•用作增加安全關鍵代碼安全程序中的內存使用和軟件cryptograhic惟一ID的結合原語和協議在編程內存。
•激活安全引導過程
