對于新設計推薦使用性能更好的器件：MAX1674/MAX1675/MAX1676
現備有評估板： MAX756EVKIT
| 關鍵特性 | 應用/使用 | |||||||||||||||||
|
|
| Key Specifications: Step-Up Switching Regulators | ||||||||||||||||||||||||
| Part Number | VIN (V) |
VIN (V) |
VOUT (V) |
VOUT (V) |
Max. IOUT (A) |
Max. IOUT (A) |
Output Adjust. Method | ICC (mA) |
DC-DC Outputs | Oper. Freq. (kHz) |
Features | EV Kit | Package/Pins | Smallest Available Pckg. (mm2) |
Oper. Temp. (°C) |
Price | ||||||||
| min | max | min | max | ≥ | ≤ | max | max w/pins | See Notes | ||||||||||||||||
| MAX757 | 0.7 | 5.5 | 2.7 | 5.5 | 0.3 | 0.3 | Resistor | 0.06 | 1 | 500 |
|
Yes |
|
31 |
|
$1.95 @1k | ||||||||
| See All Step-Up Switching Regulators (92) | ||||||||||||||||||||||||
相關型號
| PART | TEMP. RANGE | PIN-PACKAGE |
| MAX756CPA MAX756CSA MAX756C/D MAX756EPA MAX756ESA MAX757CPA MAX757CSA MAX757C/D MAX757EPA MAX757ESA |
0°C to +70°C 0°C to +70°C 0°C to +70°C -40°C to +85°C -40°C to +85°C 0°C to +70°C 0°C to +70°C 0°C to +70°C -40°C to +85°C -40°C to +85°C |
8 Plastic DIP 8 SO Dice* 8 Plastic DIP 8 SO 8 Plastic DIP 8 SO Dice* 8 Plastic DIP 8 SO |
