相關型號
| PART | TEMP. RANGE | PIN-PACKAGE |
| MAX756CPA | 0°C to +70°C | 8 Plastic DIP |
| MAX756CSA | 0°C to +70°C | 8 SO |
| MAX756C/D | 0°C to +70°C | Dice* |
| MAX756EPA | -40°C to +85°C | 8 Plastic DIP |
| MAX756ESA | -40°C to +85°C | 8 SO |
| MAX757CPA | 0°C to +70°C | 8 Plastic DIP |
| MAX757CSA | 0°C to +70°C | 8 SO |
| MAX757C/D | 0°C to +70°C | Dice* |
| MAX757EPA | -40°C to +85°C | 8 Plastic DIP |
| MAX757ESA | -40°C to +85°C | 8 SO |
| 概述 | ||||||
MAX756/MAX757提供三個比上年設備改進。物理尺寸減小，高開關頻率（高達0.5MHz）由MOSFET功率晶體管可能允許小（“5毫米直徑）表面貼裝磁性。效率提高到87％（10％比低電壓穩壓器采用雙極工藝制造）。電源電流降至60μA用CMOS建設和獨特的恒定關斷時間的脈沖頻率調制控制方案。 |
||||||
下載
現備有評估板： MAX756EVKIT
| 關鍵特性 | 應用/使用 | |||||||||||||||||
|
|
| Key Specifications: Step-Up Switching Regulators | ||||||||||||||||||||||||
| Part Number | VIN (V) |
VIN (V) |
VOUT (V) |
VOUT (V) |
Max. IOUT (A) |
Max. IOUT (A) |
Output Adjust. Method | ICC (mA) |
DC-DC Outputs | Oper. Freq. (kHz) |
Features | EV Kit | Package/Pins | Smallest Available Pckg. (mm2) |
Oper. Temp. (°C) |
Price | ||||||||
| min | max | min | max | ≥ | ≤ | max | max w/pins | See Notes | ||||||||||||||||
| MAX757 | 0.7 | 5.5 | 2.7 | 5.5 | 0.3 | 0.3 | Resistor | 0.06 | 1 | 500 |
|
Yes |
|
31 |
|
$1.95 @1k | ||||||||
